管台式焊接法兰截止阀(Tube type welding Flange globevalve)

入口(Inlet)：Ф3/4"(Ф15mm—Ф57 mm)对焊 ( butt welding)

出口(Outlet)：1/2"—2"(DN15—DN50)法兰(GB,HG,JB,ANSI,DIN等标准)(RF，RTJ)

通径(Orifice):DN6 —DN10

压力等级(Working Pressure):1.6MPa—40MPa,150lb—2500lb

适用温度(Suitable temperature)): -96℃—250℃)

材质(Materials): 316L.316SS.316H.304SS.321SS.1Cr18Ni9Ti.20#.A105.

16mu.LF2.Duplex2205.Duper duplex2507.Monel.inconel.hastelloyc
