H41H法兰式止回阀(flange check valve)

入口(Inlet)：3/8"—2"(DN10—DN50)法兰Flange(GB,HG,JB,ANSI,DIN等标准)(Optional standard)

出口(Outlet)：3/8"—2"(DN10—DN50)法兰Flange(GB,HG,JB,ANSI,DIN等标准)(Optional standard)

压力等级(Working Pressure):1.6MPa—40MPa,150lb—2500lb

打开压力(opening pressure):1/3 PSi(0.002 MPa) —25 PSi(0.17 MPa)

适用温度(Suitable temperature): -54℃—≤250℃. -9℃—≤450℃

材质(Materials): 316L.316SS.316H.304SS.321SS.1Cr18Ni9Ti.20#.A105.

.Duplex2205.Duper duplex2507.Monel.inconel.hastelloyc
